Product Features
High-quality batteries built specifically for diesel generators with nano-formulation technology material, longer charge retention capacity.
High-quality circuit breaker, safe-guarding your generators from damage caused by excess current from an overload or short circuit.
High-quality air filter, with adequate air intake, will ensure our generators are reliable in the field and bring you stable power output.
Original Perkins starter motor, built with quality in mind, will start the generators smoothly each and every time and ensure generators perform at its best in the long run.
Ease-to-use refueling port, produced with quality material, strong sealing properties.
Custom-built foam with strong ability of sound absorption, heat insulation, flame retardant, high temperature resistance, and water absorption.
World-class Stamford alternator, buit with the world’s leading alternator technology, portable size, light weight, durable performance.
Quality oil pressure sensors, designed to assist in engine control, and can be used to provide a visible warning to the operator when oil levels are low.
UK-imported DSE generator controller, designed and manufactured by DSE industry leading experts to deliver rich features and benefits and provide outstanding performance.
Product Specification
| Genset Model |
Hz | Prime Power (KW) |
Prime Power (KVA) |
Standby Power (KW) |
Standby Power (KVA) |
Engine Model |
Alternator Model (Stamford) | Cylinder*Bore*Stroke (Qty*mm*mm) | Displacement (L) |
Open Type Dimension (mm) |
|---|---|---|---|---|---|---|---|---|---|---|
| GF-8KW | 50 | 8 | 10 | 9 | 11 | 403A-11G1 | PI044E-8KW | 3*77*81 | 1.131 | 1320*552*1180 |
| GF-10KW | 50 | 10 | 13 | 11 | 14 | 403A-15G1(M) | PI044F-10KW | 3*84*90 | 1.496 | 1320*552*1180 |
| GF-12KW | 50 | 12 | 15 | 13 | 17 | 403A-15G2(M) | PT044G-12KW | 3*84*90 | 1.496 | 1320*552*1180 |
| GF-16KW | 50 | 16 | 20 | 18 | 22 | 404A-22G1(M) | PI144D-16KW | 4*84*100 | 2.216 | 1320*552*1180 |
| GF-22KW | 50 | 22 | 28 | 24 | 30 | 404D-22TG(E) | PI144F-22KW | 4*84*100 | 2.216 | 1350*552*1180 |
| GF-24KW | 50 | 24 | 30 | 26 | 33 | 1103A-33G(M)/India | PI144G-24KW | 3*105*127 | 3.3 | 1770*710*1350 |
| GF-36KW | 50 | 36 | 45 | 40 | 50 | 1103A-33TG1(M)/India | UCI224D-40KW | 3*105*127 | 3.3 | 2140*750*1360 |
| GF-48KW | 50 | 48 | 60 | 53 | 66 | 1103A-33TG2(M)/India | UCI224E-48KW | 3*105*127 | 3.3 | 2400*750*1500 |
| GF-52KW | 50 | 52 | 65 | 57 | 72 | 1104A-44TG1(M) | UCI224F-58KW | 4*105*127 | 4.4 | 2500*760*1550 |
| GF-64KW | 50 | 64 | 80 | 70 | 88 | 1104A-44TG2(M) | UCI224G-68KW | 4*105*127 | 4.4 | 2500*760*1550 |
| GF-80KW | 50 | 80 | 100 | 88 | 110 | 1104C-44TAG2(E) | UCI274C-80KW | 4*105*127 | 4.4 | 2370*740*1400 |
| GF-108KW | 50 | 108 | 135 | 119 | 149 | 1106A-70TG1(E) | UCI274E-112KW | 6*105*127 | 7 | 2700*900*1450 |
| GF-120KW | 50 | 120 | 150 | 132 | 165 | 1106A-70TAG2 | UCI274F-128KW | 6*105*127 | 7 | 2700*900*1450 |
| GF-144KW | 50 | 144 | 180 | 158 | 198 | 1106A-70TAG3(M) | UCI274G-145.5KW | 6*105*127 | 7 | 2700*900*1450 |
| GF-160KW | 50 | 160 | 200 | 176 | 220 | 1106A-70TAG4(M) | UCI274H-160KW | 6*105*127 | 7 | 2700*900*1450 |
| GF-184KW | 50 | 184 | 230 | 202 | 253 | 1506A-E88TAG2£¨ECM)/USA | UCDI274J-184KW | 6*112*149 | 8.8 | 2700*1005*1720 |
| GF-200KW | 50 | 200 | 250 | 220 | 275 | 1206A-E70TTAG3/GBP | UCDI274K-200KW | 6*105*135 | 7 | 2700*1005*1720 |
| GF-240KW | 50 | 240 | 300 | 264 | 330 | 1506A-E88TAG5(ECM)/USA | HCI444D-240KW | 6*112*149 | 8.8 | 2850*1005*1820 |
| GF-280KW | 50 | 280 | 350 | 308 | 385 | 2206C-E13TAG2(ECM)/USA | HCI444E-280KW | 6*130*157 | 12.5 | 3400*1110*2100 |
| GF-320KW | 50 | 320 | 400 | 352 | 440 | 2206C-E13TAG3(ECM)/USA | HCI444F-320KW | 6*137*171 | 12.5 | 3400*1110*2100 |
| GF-400KW | 50 | 400 | 500 | 440 | 550 | 2506C-E15TAG2(ECM)/USA | HCI544C-400KW | 6*137*171 | 15.2 | 3700*1150*2150 |
| GF-480KW | 50 | 480 | 600 | 528 | 660 | 2806C-E18TAG1A(ECM)/USA | HCI544E-488KW | 6*145*183 | 18.1 | 4000*1500*2200 |
| GF-520KW | 50 | 520 | 650 | 572 | 715 | 2806A-E18TAG2(ECM)/USA | HCI544F-536KW | 6*145*183 | 18.1 | 4000*1500*2200 |
| GF-640KW | 50 | 640 | 800 | 704 | 880 | 4006-23TAG3A/India/GBP | HCI634G-648KW | 6*160*190 | 22.921 | 4200*1900*2270 |
| GF-720KW | 50 | 720 | 900 | 792 | 990 | 4008TAG1A/India/GBP | HCI634H-752KW | 8*160*190 | 30.561 | 4800*2000*2250 |
| GF-800KW | 50 | 800 | 1000 | 880 | 1100 | 4008TAG2A/India/GBP | HCI634J-824KW | 8*160*190 | 30.561 | 4800*2000*2250 |
| GF-900KW | 50 | 900 | 1125 | 990 | 1238 | 4008-30TAG3/India/GBP | HCI634K-908KW | 8*160*190 | 30.561 | 4800*2000*2250 |
| GF-1000KW | 50 | 1000 | 1250 | 1100 | 1375 | 4012-46TWG2A/India/GBP | LVI634G-1000KW | 12*160*190 | 45.842 | 4900*2000*2300 |
